Cisco Meraki MA-ANT-27 Dual-Band Sector Antenna
Cisco Meraki MA-ANT-27 Dual-Band Sector Antenna
Save $218.08 (47%)
Unit price perFree shipping on orders of $299 or more
Returning customer or larger project? Contact us for premium pricing.
Couldn't load pickup availability
- Cisco Partner
- 2-hour guaranteed response, Mon–Fri 8am–5pm CT
- Call 1-800-768-7875 Press 1 for 24/7 support · 2 for sales
Not sure what you need? Our US-based Cisco certified engineers will help you build the right solution.
Planning a larger deployment? Request a quote for project and volume pricing.
Meraki Antennas FAQ
Outdoor dual-band 9 dBi / 12 dBi sector antenna for the Cisco Meraki MR76 and MR86 outdoor access points.
- Dual-band sector: 9 dBi (2.4 GHz) / 12 dBi (5 GHz)
- Half-power beamwidth: 86°/65° horizontal, 34°/18° vertical (2.4/5 GHz)
- Two integrated pigtail cables with N connectors
- 9.1 x 5.5 x 1.9 in (230 x 140 x 48 mm), 1.4 lb (0.630 kg)
- Operating temperature: –40° to 158° F (–40° to 70° C)
Compatible with: MR76 and MR86. Use quantity 2 on the MR86 (4x4:4), with both antennas aimed the same way. Not for the CW9163E.
Cisco part number: MA-ANT-27
Cisco GPL description: Meraki Dual Band Sector Antenna
