Cisco Meraki MA-ANT-20 Dual-Band Omni Antennas (Set of 2)
Cisco Meraki MA-ANT-20 Dual-Band Omni Antennas (Set of 2)
Save $124.35 (47%)
Unit price perFree shipping on orders of $299 or more
Returning customer or larger project? Contact us for premium pricing.
Couldn't load pickup availability
- Cisco Partner
- 2-hour guaranteed response, Mon–Fri 8am–5pm CT
- Call 1-800-768-7875 Press 1 for 24/7 support · 2 for sales
Not sure what you need? Our US-based Cisco certified engineers will help you build the right solution.
Planning a larger deployment? Request a quote for project and volume pricing.
Meraki MR Accessories
Outdoor dual-band (2.4 GHz and 5 GHz) omnidirectional antennas for the Cisco Meraki MR76 and MR86 outdoor access points. Sold as a set of two.
- Omnidirectional; 2.400–2.500 GHz and 5.150–5.875 GHz
- Gain: 4 dBi (2.4 GHz) / 7 dBi (5 GHz)
- Half-power beamwidth: 360° horizontal, 45° vertical
- N-type connector; attaches directly to the access point
- Contains two MA-ANT-20 antennas
- Each antenna: 1.0 x 7.1 in (25 x 180 mm), 0.17 lb (0.079 kg)
- Operating temperature: –40° to 158° F (–40° to 70° C)
Compatible with: MR76 and MR86. The MR86 (4x4:4) should have the same antenna on all four ports, so use two sets. Not for the CW9163E.
Cisco part number: MA-ANT-20
Cisco GPL description: Meraki Dual-band Omni Antennas
