Cisco CW-ANT-O1-NS-00 Tri-Band Omni Antenna for CW9163E
Cisco CW-ANT-O1-NS-00 Tri-Band Omni Antenna for CW9163E
Save $132.72 (47%)
Unit price perFree shipping on orders of $299 or more
Returning customer or larger project? Contact us for premium pricing.
Couldn't load pickup availability
- Cisco Partner
- 2-hour guaranteed response, Mon–Fri 8am–5pm CT
- Call 1-800-768-7875 Press 1 for 24/7 support · 2 for sales
Not sure what you need? Our US-based Cisco certified engineers will help you build the right solution.
Planning a larger deployment? Request a quote for project and volume pricing.
Meraki MR Accessories
Outdoor-rated 2.4 GHz + 5 GHz + 6 GHz self-identifying omnidirectional dipole antenna for the Cisco CW9163E access point.
- Max gain: 4 dBi (2.4 GHz), 8 dBi (5 GHz and 6 GHz)
- Azimuth: omni; elevation (3 dB beamwidth): 30° on each band
- Direct connect, N-type (M) connector
- Self-identifying antenna (SIA)
- Sold individually (not a set of two)
- 1.0 x 8.875 in (25 x 225 mm), 0.25 lb (0.115 kg)
- Operating temperature: –40° to 158° F (–40° to 70° C)
Compatible with: CW9163E. No antennas are included with the CW9163E-MR access point. Do not use the older dual-band MA-ANT-20/21/23/25/27 on the CW9163E.
Cisco part number: CW-ANT-O1-NS-00
Cisco GPL description: 4/8/8 dBi Omni Dipole, N connector, Catalyst and Meraki
